Eaton 7 Ammeter Position Selector Switch (T0-3-8048/E)

Manufacturer Part No: T0-3-8048/E

Eaton 7 Ammeter Position Selector Switch (T0-3-8048/E)

Manufacturer Part No: T0-3-8048/E

£12.70

£15.24 inc. VAT

Product Description

Hobut's Selector Switches are suitable for panel mount metering (Current Transformer connected) between phase currents or line and phase voltages. The modular system is particularly flexible and enables a broad range of different combinations and types.

Cam-Switches are accessible for rated un-interrupted currents from 14A to 65A in three basic designs: cover mounting, base mounting, and surface mounting (insulated enclosure). Rotary cam switches can be used in a large range of applications and are just as suitable for switching motors as they are for control circuits. The switch works as an Ammeter and has 7 configurable options from: Line 1: Line 2, Line: Line 3, Line 3: Line 1, Line 1: N, Line 2: N and Line 3: N

Specification

Current Rating 10A (AC22) (BS EN 60947-3)
Voltage Rating 500V AC (BS EN 60947-3)
Degree of Protection IP65
Maximum Cable Size 4mm²
Temperature Ranges -20ºC to +40ºC
